The invention discloses a threephase LCL type gridconnected inverter control system based on pole assignment, and the gridconnected inverter control system restrains the influence of power grid impedance on a threephase LCL type gridconnected inverter, can effectively solve the problem that a gridconnected system is instable due to the power grid impedance and can be used for current control over the gridconnected inverter. A gridconnected control method not only can achieve system stability and highquality grid connection under the condition of a weak grid, but also avoids the complex design of a current controller, coordinate rotation transformation and decoupling control. Meanwhile, the gridconnected control method can automatically adjust gridconnected current reference values to achieve independent control over reactive power according to given signals of externallyset reactive power. Therefore, the gridconnected control method is more suitable for controlling the photovoltaic power station gridconnected inverter which is connected into the weak grid through a longdistance power transmission line.
Description
Technical field
The present invention relates to combining inverter Current Control field, particularly a kind of LCL type parallel inverter current control method that suppresses the electric network impedance impact.
Background technology
Photovoltaic generation is one of generation of electricity by new energy form of the outer tool development prospect of Present Domestic, and generate electricity by way of merging two or more grid systems, becomes the Main Trends of The Development that the scale photovoltaic utilizes.It is one of effective means suppressed the highfrequency current harmonic wave that photovoltaic combining inverter adopts the LCL filter, in the situation that same inductance value, the LCL filter is widely adopted because the successful of filtering high order harmonic component is better than the Ltype filter.
Yet, when the distributed photovoltaic power station is connected with electrical network by an electric network impedance different from its original design, can cause inverter dynamic performance significantly to degenerate, even unstable.Along with the continuous expansion of photovoltaic generation permeability, the wild effect caused by electric network impedance may have a strong impact on the stable operation of whole photovoltaic parallel in system.Therefore, existing many scholars have proposed new current controller method for designing in fields such as windpowered electricity generation, Active Power FilterAPF, distributed power generations, thereby suppress the impact of electric network impedance on the inverter control performance.Yet the design of its controller is complicated, dynamic response is slow, have shake in control procedure and when electric network impedance changes greatly the drawbacks limit such as easy inefficacy the extensive use of the control method that proposes.
Therefore, be badly in need of a kind of LCL type combining inverter current control system and method that suppresses the electric network impedance impact, for the combining inverter Current Control.
Summary of the invention
In view of this, technical problem to be solved by this invention is to provide a kind of threephase LCL type combining inverter control system and method based on POLE PLACEMENT USING.
One of purpose of the present invention is to propose a kind of threephase LCL type combining inverter control system based on POLE PLACEMENT USING; Two of purpose of the present invention is to propose a kind of threephase LCL type control method of gridconnected inverter based on POLE PLACEMENT USING.
One of purpose of the present invention is achieved through the following technical solutions:
Threephase LCL type combining inverter control system based on POLE PLACEMENT USING provided by the invention, comprise direct current input source, DC voltage detection module, inverter, inversion side current detection module, LCL filter, filter capacitor voltage detection module, gridconnected side current detection module, gridconnected point voltage detection module, the outer ring controller of power, gridconnected reference current synthesis module, current loop controller, variable gain factor module, POLE PLACEMENT USING module and SPWM unit;
Described direct current input source, for connecting outside direct current input source;
Described DC voltage detection module, for gathering DC side voltage of converter;
Described inverter, for realizing the conversion of direct current to alternating current;
Described inversion side current detection module, for gathering inversion side threephase alternating current;
Described LCL filter, for the highfrequency harmonic component of filtering inversion side output current;
Described filter capacitor voltage detection module, for gathering the threephase alternating voltage of LCL filter filter capacitor;
Described gridconnected side current detection module, for gathering gridconnected side threephase alternating current;
Described gridconnected point voltage detection module, for gathering and the site threephase alternating voltage;
The outer ring controller of described power, for stablizing DC side voltage of converter;
Described gridconnected reference current synthesis module, for calculating the gridconnected current setpoint;
Described current loop controller, for regulating gridconnected side current tracking gridconnected current setpoint;
Described variable gain factor module and POLE PLACEMENT USING module, for suppressing the impact of electric network impedance on the stability of a system;
Described SPWM unit, for providing the SPWM modulation signal, the conducting of control inverter switching device or shutoff;
Described direct current input source is connected with the input of inverter, and the output of described inverter is connected with the input of LCL filter, and the output of described LCL filter is connected with electrical network;
The inversion side of described LCL filter and gridconnected side are respectively arranged with inversion side current detection module and gridconnected side current detection module, the filter capacitor place of LCL filter is provided with the filter capacitor voltage detection module, and the output of described inversion side current detection module and filter capacitor voltage detection module is connected with the input of POLE PLACEMENT USING module; The output of described gridconnected side current detection module is connected with the input of POLE PLACEMENT USING module and current loop controller respectively;
The input of described POLE PLACEMENT USING module is connected with the output of inversion side current detection module, filter capacitor voltage detection module and gridconnected side current detection module, and input signal is multiplied by respectively the state variable feedback gain coefficient k of inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module
_{1}, k
_{3}, k
_{2}rear formation state feedback signal, will do poor the connection with the output of variable gain factor module after above three state feedback signal plus;
Described and site is provided with voltage detection module, described gridconnected point voltage detection module output with the input of reference current synthesis module, be connected; The output of described reference current synthesis module is connected with the input of current loop controller, and the output of described current loop controller is connected with the input of variable gain factor module; The output of described variable gain factor module is done poor the connection with the output of described POLE PLACEMENT USING module, then with the input of SPWM unit, is connected;
Described inverter directflow side is provided with the DC side voltage of converter detection module, after the output of described DC side voltage of converter detection module and reference voltage signal are made difference, with the input of the outer ring controller of power, be connected, after the output signal of the outer ring controller of described power and the output multiplication of DC side voltage of converter detection module, output is connected with the input of reference current synthesis module.
Further, also comprise the referential modular converter;
Described referential modular converter, for realizing the conversion between three phase static referential and twophase stationary reference frame;
The output of described inversion side current detection module, gridconnected side current detection module and filter capacitor voltage detection module is connected with the input of referential modular converter; The output of output after the referential modular converter of described inversion side current detection module and filter capacitor voltage detection module is connected with the input of POLE PLACEMENT USING module; The output of the output of described gridconnected side current detection module after the referential modular converter is connected with the input of POLE PLACEMENT USING module and current loop controller respectively;
The output of described gridconnected point voltage detection module is connected with the input of referential modular converter; The output of the output of described gridconnected point voltage detection module after the referential modular converter is connected with the input of reference current synthesis module; The output of described reference current synthesis module is connected with the input of current loop controller, and the output of described current loop controller is connected with the input of variable gain factor module; The output of described variable gain factor module is done poor the connection with the output of described POLE PLACEMENT USING module, then with the input of referential modular converter, is connected; The output of described referential modular converter is connected with the input of SPWM unit.
Further, the outer ring controller of described power adopts the PI controller of lowpass filter, the transfer function G of the outer ring controller of described PI power
_{cv}(s) expression formula is:
In formula, τ
_{0}mean proportionality constant, τ
_{2}mean integration time constant, τ
_{1}mean derivative time constant, s means that the transfer function expression formula provides with Laplce's form.
Further, described gridconnected reference current synthesis module, calculate the gridconnected current setpoint by following formula:
Wherein,
be illustrated in the gridconnected current setpoint under the α stationary reference frame,
be illustrated in the gridconnected current setpoint under the β stationary reference frame, u
_{α}be illustrated in the gridconnected point voltage positive sequence fundametal compoment under the α stationary reference frame, u
_{β}be illustrated in the line voltage positive sequence fundametal compoment under the β stationary reference frame, Q
_{ref}mean the instantaneous reactive power setpoint, P
_{ref}mean the instantaneous active power setpoint.
Further, described current loop controller adopts accurate PR+HC current controller; The transfer function G of described accurate PR+HC current controller
_{c}(s) expression formula is:
In formula, k
_{p}mean proportional gain, h means firstharmonic and each harmonic component, k
_{rh}mean the improper integral coefficient, ω
_{c}mean the controller bandwidth factor, ω
_{1}mean resonance angular frequency, ω
_{1}the line voltage fundamental frequency of being extracted by gridconnected common point, s means that the transfer function expression formula provides with Laplce's form.
Further, described variable gain module, calculate variable gain factor k in described variable gain factor module by following formula
_{a}:
Wherein, L
_{2}mean the gridconnected side inductance parameters of LCL filter value, L
_{g}mean equivalent inductance parameters value in electric network impedance.
Further, described POLE PLACEMENT USING module produces the unsure state feedback signal for suppressing the LCL filter resonance and being caused by electric network impedance; The state feedback signal of described POLE PLACEMENT USING module output obtains by following steps:
At first, calculate by following formula the active damping coefficient k that suppresses the LCL filter resonance
_{c}:
Wherein, ζ means system damping ratio, L
_{1}, L
_{2}, C
_{f}mean respectively LCL filter inverter side inductance, gridconnected side inductance and filter capacitor;
Then, calculate feedback factor in the POLE PLACEMENT USING module by following formula:
In formula, k
_{1}, k
_{3}, k
_{2}the state variable feedback gain coefficient that means respectively inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, k
_{pwm}mean that modulating wave is to inverter bridge outputtransfer function, L
_{g}, R
_{g}mean respectively equivalent inductance and equivalent resistance in electric network impedance;
The state variable feedback gain coefficient k of inverter output current in the POLE PLACEMENT USING module is multiplied by the output of inversion side current detection module after the referential modular converter
_{1}, the state variable feedback gain coefficient k of gridconnected current in the POLE PLACEMENT USING module is multiplied by the output of gridconnected side current detection module after the referential modular converter
_{3}, the state variable feedback gain coefficient k of capacitance voltage in the POLE PLACEMENT USING module is multiplied by the output of filter capacitor voltage detection module after the referential modular converter
_{2}, will form the state feedback signal after above three output signal additions.
Further, described SPWM unit produces the modulation signal for adjusting current on line side by the output signal of calculating variable gain module and the difference of state feedback signal, and modulation signal is input in the SPWM unit and compares the SPWM pulsemodulated signal of generation for the control inverter switch with the triangular carrier signal;
Described POLE PLACEMENT USING module and variable gain factor module are to adopt the feedback control module that realizes POLE PLACEMENT USING based on the system mode feedback; Described reference current synthesis module is by being synthesized based on instantaneous active power P and reactive power Q under α β stationary reference frame.
Two of purpose of the present invention is achieved through the following technical solutions:
Threephase LCL type control method of gridconnected inverter based on POLE PLACEMENT USING provided by the invention comprises the following steps:
S1: form directcurrent reference current by the outer ring controller of power, stablize DC side voltage of converter; The outer ring controller of described power adopts the PI controller of lowpass filter, the transfer function G of the outer ring controller of described PI power
_{cv}(s) expression formula is:
In formula, τ
_{0}mean proportionality constant, τ
_{2}mean integration time constant, τ
_{1}mean derivative time constant, s means that the transfer function expression formula provides with Laplce's form;
S2: by following formula, calculate the gridconnected current setpoint:
Wherein,
be illustrated in the gridconnected current setpoint under the α stationary reference frame,
be illustrated in the gridconnected current setpoint under the β stationary reference frame, u
_{α}be illustrated in the gridconnected point voltage positive sequence fundametal compoment under the α stationary reference frame, u
_{β}be illustrated in the line voltage positive sequence fundametal compoment under the β stationary reference frame, Q
_{ref}mean the instantaneous reactive power setpoint, P
_{ref}mean the instantaneous active power setpoint;
The output signal of described gridconnected side current detection module is after the referential modular converter, poor with the gridconnected current setpoint, the input of its formed error signal input current ring controller;
S3: by the current loop controller effect, produce for regulating the also conditioning signal of current on line side, described current loop controller adopts accurate PR+HC current controller; The transfer function G of described accurate PR+HC current controller
_{c}(s) expression formula is:
In formula, k
_{p}mean proportional gain, h means firstharmonic and each harmonic component, k
_{rh}mean the improper integral coefficient, ω
_{c}mean the controller bandwidth factor, ω
_{1}mean resonance angular frequency, ω
_{1}the line voltage fundamental frequency of being extracted by gridconnected common point, s means that the transfer function expression formula provides with Laplce's form;
S4: the output regulation signal of current loop controller, adjust the size of current loop controller output regulation signal by variable gain module, eliminate the impact of electric network impedance on conditioning signal; Calculate variable gain factor k in described variable gain factor module by following formula
_{a}:
Wherein, L
_{2}mean the gridconnected side inductance parameters of LCL filter value, L
_{g}mean equivalent inductance parameters value in electric network impedance;
S5: gather inversion side electric current, filter capacitor voltage and and current on line side be input to the POLE PLACEMENT USING module;
S6: the state feedback signal that produces the wild effect for suppressing the LCL filter resonance and being caused by electric network impedance by the POLE PLACEMENT USING module;
State variable feedback gain coefficient in described POLE PLACEMENT USING module obtains by following steps:
At first, calculate by following formula the active damping coefficient k c that suppresses the LCL filter resonance:
Wherein, ζ means system damping ratio, L
_{1}, L
_{2}, C
_{f}mean respectively LCL filter inverter side inductance, gridconnected side inductance and filter capacitor;
Then, calculate feedback factor in the POLE PLACEMENT USING module by following formula:
In formula, k
_{1}, k
_{3}, k
_{2}the state variable feedback gain coefficient that means respectively inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, k
_{pwm}mean that modulating wave is to inverter bridge outputtransfer function, L
_{g}, R
_{g}mean respectively equivalent inductance and equivalent resistance in electric network impedance.
The state variable feedback gain coefficient k of inverter output current in the POLE PLACEMENT USING module is multiplied by the output of inversion side current detection module after the referential modular converter
_{1}, the state variable feedback gain coefficient k of gridconnected current in the POLE PLACEMENT USING module is multiplied by the output of gridconnected side current detection module after the referential modular converter
_{3}, the state variable feedback gain coefficient k of capacitance voltage in the POLE PLACEMENT USING module is multiplied by the output of filter capacitor voltage detection module after the referential modular converter
_{2}, will after above three output additions, form the state feedback signal;
S7: calculate the output signal of variable gain module and the difference of state feedback signal and produce for regulating the also modulation signal of current on line side, modulation signal is input in the SPWM unit and compares with the triangular carrier signal SPWM pulsemodulated signal produced for the control inverter switch.
Further, described POLE PLACEMENT USING module and variable gain factor module are to adopt the feedback control module that realizes POLE PLACEMENT USING based on the system mode feedback; Described reference current synthesis module is by being synthesized based on instantaneous active power P and reactive power Q under α β stationary reference frame.
The invention has the advantages that: during the present invention considers that by the electric network impedance factor largesized photovoltaic electric station grid connection is controlled, provide a kind of LCL type control method of gridconnected inverter and system that suppresses the electric network impedance impact, by combining inverter power output and gridconnected point voltage, calculated gridconnected reference current value; Also to generate for regulating the also conditioning signal of current on line side; By the inversion side electric current that collects, filter capacitor voltage and and current on line side be input to the POLE PLACEMENT USING module and produce the state feedback signal; Preferably calculate the poor of conditioning signal and state feedback signal, and, after the variable gain factor module is amplified, be input to the SPWM unit and produce the SPWM modulation signal for the control inverter switch; Stablize the unsettled phenomenon of the electrical network caused by electric network impedance, suppressed the impact of electric network impedance on the inverter control performance.The method controller simplicity of design, dynamic response are fast, in control procedure steadily and also be not easy inefficacy when electric network impedance changes greatly.
The accompanying drawing explanation
In order to make the purpose, technical solutions and advantages of the present invention clearer, below in conjunction with accompanying drawing, the present invention is described in further detail, wherein:
The threephase LCL type combining inverter control system structure chart based on POLE PLACEMENT USING that Fig. 1 provides for the embodiment of the present invention;
The threephase LCL type control method of gridconnected inverter flow chart based on POLE PLACEMENT USING that Fig. 2 provides for the embodiment of the present invention.
Embodiment
Below with reference to accompanying drawing, the preferred embodiments of the present invention are described in detail; Should be appreciated that preferred embodiment is only for the present invention is described, rather than in order to limit the scope of the invention.
The threephase LCL type combining inverter control system structure chart based on POLE PLACEMENT USING that Fig. 1 provides for the embodiment of the present invention, as shown in the figure: the threephase LCL type combining inverter control system based on POLE PLACEMENT USING provided by the invention, comprise the direct current input source, the DC voltage detection module, inverter, inversion side current detection module, the LCL filter, the filter capacitor voltage detection module, gridconnected side current detection module, gridconnected point voltage detection module, the outer ring controller of power, gridconnected reference current synthesis module, current loop controller, the variable gain factor module, POLE PLACEMENT USING module and SPWM unit,
Described direct current input source, for connecting outside direct current input source;
Described DC voltage detection module, for gathering DC side voltage of converter;
Described inverter, for realizing the conversion of direct current to alternating current;
Described inversion side current detection module, for gathering inversion side threephase alternating current;
Described LCL filter, for the highfrequency harmonic component of filtering inversion side output current;
Described filter capacitor voltage detection module, for gathering the threephase alternating voltage of LCL filter filter capacitor;
Described gridconnected side current detection module, for gathering gridconnected side threephase alternating current;
Described gridconnected point voltage detection module, for gathering and the site threephase alternating voltage;
The outer ring controller of described power, for stablizing DC side voltage of converter;
Described gridconnected reference current synthesis module, for calculating the gridconnected current setpoint;
Described current loop controller, for regulating gridconnected side current tracking gridconnected current setpoint;
Described variable gain factor module and POLE PLACEMENT USING module, for suppressing the impact of electric network impedance on the stability of a system;
Described SPWM unit, for providing the SPWM modulation signal, the conducting of control inverter switching device or shutoff;
Described direct current input source is connected with the input of inverter, and the output of described inverter is connected with the input of LCL filter, and the output of described LCL filter is connected with electrical network;
The inversion side of described LCL filter and gridconnected side are respectively arranged with inversion side current detection module and gridconnected side current detection module, the filter capacitor place of LCL filter is provided with the filter capacitor voltage detection module, and the output of described inversion side current detection module and filter capacitor voltage detection module is connected with the input of POLE PLACEMENT USING module; The output of described gridconnected side current detection module is connected with the input of POLE PLACEMENT USING module and current loop controller respectively;
The input of described POLE PLACEMENT USING module is connected with the output of inversion side current detection module, filter capacitor voltage detection module and gridconnected side current detection module, input signal forms the state feedback signal after being multiplied by respectively the state variable feedback gain coefficient k1, k3, k2 of inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, will after above three state feedback signal plus, with the output of variable gain factor module, do poor the connection;
Described and site is provided with voltage detection module, described gridconnected point voltage detection module output with the input of reference current synthesis module, be connected; The output of described reference current synthesis module is connected with the input of current loop controller, and the output of described current loop controller is connected with the input of variable gain factor module; The output of described variable gain factor module is done poor the connection with the output of described POLE PLACEMENT USING module, then with the input of SPWM unit, is connected;
Described inverter directflow side is provided with the DC side voltage of converter detection module, after the output of described DC side voltage of converter detection module and reference voltage signal are made difference, with the input of the outer ring controller of power, be connected, after the output signal of the outer ring controller of described power and the output multiplication of DC side voltage of converter detection module, output is connected with the input of reference current synthesis module.
Above control system can be controlled under the three phase static coordinate system, also can be by reference to being that modular converter is inputted signal in corresponding module and processed.
Also comprise the referential modular converter;
Described referential modular converter, for realizing the conversion between three phase static referential and twophase stationary reference frame;
The output of described inversion side current detection module, gridconnected side current detection module and filter capacitor voltage detection module is connected with the input of referential modular converter; The output of output after the referential modular converter of described inversion side current detection module and filter capacitor voltage detection module is connected with the input of POLE PLACEMENT USING module; The output of the output of described gridconnected side current detection module after the referential modular converter is connected with the input of POLE PLACEMENT USING module and current loop controller respectively;
The output of described gridconnected point voltage detection module is connected with the input of referential modular converter; The output of the output of described gridconnected point voltage detection module after the referential modular converter is connected with the input of reference current synthesis module; The output of described reference current synthesis module is connected with the input of current loop controller, and the output of described current loop controller is connected with the input of variable gain factor module; The output of described variable gain factor module is done poor the connection with the output of described POLE PLACEMENT USING module, then with the input of referential modular converter, is connected; The output of described referential modular converter is connected with the input of SPWM unit.
The outer ring controller of described power adopts the PI controller of lowpass filter, the transfer function G of the outer ring controller of described PI power
_{cv}(s) expression formula is:
In formula, τ
_{0}mean proportionality constant, τ
_{2}mean integration time constant, τ
_{1}mean derivative time constant, s means that the transfer function expression formula provides with Laplce's form.
Described gridconnected reference current synthesis module, calculate the gridconnected current setpoint by following formula:
Wherein,
be illustrated in the gridconnected current setpoint under the α stationary reference frame,
be illustrated in the gridconnected current setpoint under the β stationary reference frame, u
_{α}be illustrated in the gridconnected point voltage positive sequence fundametal compoment under the α stationary reference frame, u
_{β}be illustrated in the line voltage positive sequence fundametal compoment under the β stationary reference frame, Q
_{ref}mean the instantaneous reactive power setpoint, P
_{ref}mean the instantaneous active power setpoint.
Described current loop controller adopts accurate PR+HC current controller; The transfer function G of described accurate PR+HC current controller
_{c}(s) expression formula is:
In formula, k
_{p}mean proportional gain, h means firstharmonic and each harmonic component, k
_{rh}mean the improper integral coefficient, ω
_{c}mean the controller bandwidth factor, ω
_{1}mean resonance angular frequency, ω
_{1}the line voltage fundamental frequency of being extracted by gridconnected common point, s means that the transfer function expression formula provides with Laplce's form.
Described variable gain module, calculate variable gain factor k in described variable gain factor module by following formula
_{a}:
Wherein, L
_{2}mean the gridconnected side inductance parameters of LCL filter value, L
_{g}mean equivalent inductance parameters value in electric network impedance.
Described POLE PLACEMENT USING module produces the unsure state feedback signal for suppressing the LCL filter resonance and being caused by electric network impedance; The state feedback signal of described POLE PLACEMENT USING module output obtains by following steps:
At first, calculate by following formula the active damping coefficient k that suppresses the LCL filter resonance
_{c}:
Wherein, ζ means system damping ratio, L
_{1}, L
_{2}, C
_{f}mean respectively LCL filter inverter side inductance, gridconnected side inductance and filter capacitor;
Then, calculate feedback factor in the POLE PLACEMENT USING module by following formula:
In formula, k
_{1}, k
_{3}, k
_{2}the state variable feedback gain coefficient that means respectively inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, k
_{pwm}mean that modulating wave is to inverter bridge outputtransfer function, L
_{g}, R
_{g}mean respectively equivalent inductance and equivalent resistance in electric network impedance;
The state variable feedback gain coefficient k of inverter output current in the POLE PLACEMENT USING module is multiplied by the output of inversion side current detection module after the referential modular converter
_{1}, the state variable feedback gain coefficient k of gridconnected current in the POLE PLACEMENT USING module is multiplied by the output of gridconnected side current detection module after the referential modular converter
_{3}, the state variable feedback gain coefficient k of capacitance voltage in the POLE PLACEMENT USING module is multiplied by the output of filter capacitor voltage detection module after the referential modular converter
_{2}, will form the state feedback signal after above three output signal additions.
Described SPWM unit produces the modulation signal for adjusting current on line side by the output signal of calculating variable gain module and the difference of state feedback signal, and modulation signal is input in the SPWM unit and compares the SPWM pulsemodulated signal of generation for the control inverter switch with the triangular carrier signal;
Described POLE PLACEMENT USING module and variable gain factor module are to adopt the feedback control module that realizes POLE PLACEMENT USING based on the system mode feedback; Described reference current synthesis module is by being synthesized based on instantaneous active power P and reactive power Q under α β stationary reference frame.
The threephase LCL type control method of gridconnected inverter flow chart based on POLE PLACEMENT USING that Fig. 2 provides for the embodiment of the present invention, as shown in the figure, the threephase LCL type control method of gridconnected inverter based on POLE PLACEMENT USING comprises the following steps:
S1: form directcurrent reference current by the outer ring controller of power, stablize DC side voltage of converter; The outer ring controller of described power adopts the PI controller of lowpass filter, the transfer function G of the outer ring controller of described PI power
_{cv}(s) expression formula is:
In formula, τ
_{0}mean proportionality constant, τ
_{2}mean integration time constant, τ
_{1}mean derivative time constant, s means that the transfer function expression formula provides with Laplce's form;
S2: by following formula, calculate the gridconnected current setpoint:
Wherein,
be illustrated in the gridconnected current setpoint under the α stationary reference frame,
be illustrated in the gridconnected current setpoint under the β stationary reference frame, u
_{α}be illustrated in the gridconnected point voltage positive sequence fundametal compoment under the α stationary reference frame, u
_{β}be illustrated in the line voltage positive sequence fundametal compoment under the β stationary reference frame, Q
_{ref}mean the instantaneous reactive power setpoint, P means the instantaneous active power setpoint;
The output signal of described gridconnected side current detection module is after the referential modular converter, poor with the gridconnected current setpoint, the input of its formed error signal input current ring controller;
S3: by the current loop controller effect, produce for regulating the also conditioning signal of current on line side, described current loop controller adopts accurate PR+HC current controller; The transfer function G of described accurate PR+HC current controller
_{c}(s) expression formula is:
In formula, k
_{p}mean proportional gain, h means firstharmonic and each harmonic component, k
_{rh}mean the improper integral coefficient, ω
_{c}mean the controller bandwidth factor, ω
_{1}mean resonance angular frequency, ω
_{1}the line voltage fundamental frequency of being extracted by gridconnected common point, s means that the transfer function expression formula provides with Laplce's form;
S4: the output regulation signal of current loop controller, adjust the size of current loop controller output regulation signal by variable gain module, eliminate the impact of electric network impedance on conditioning signal; Calculate variable gain factor k in described variable gain factor module by following formula
_{a}:
Wherein, L
_{2}mean the gridconnected side inductance parameters of LCL filter value, L
_{g}mean equivalent inductance parameters value in electric network impedance;
S5: gather inversion side electric current, filter capacitor voltage and and current on line side be input to the POLE PLACEMENT USING module;
S6: by the POLE PLACEMENT USING module, produce the unsure state feedback signal for suppressing the LCL filter resonance and being caused by electric network impedance;
The state feedback signal of described POLE PLACEMENT USING module output obtains by following steps:
At first, calculate by following formula the active damping coefficient k that suppresses the LCL filter resonance
_{c}:
Wherein, ζ means system damping ratio, L
_{1}, L
_{2}, C
_{f}mean respectively LCL filter inverter side inductance, gridconnected side inductance and filter capacitor;
Then, calculate feedback factor in the POLE PLACEMENT USING module by following formula:
In formula, k
_{1}, k
_{3}, k
_{2}the state variable feedback gain coefficient that means respectively inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, k
_{pwm}mean that modulating wave is to inverter bridge outputtransfer function, L
_{g}, R
_{g}mean respectively equivalent inductance and equivalent resistance in electric network impedance.
The state variable feedback gain coefficient k of inverter output current in the POLE PLACEMENT USING module is multiplied by the output of inversion side current detection module after the referential modular converter
_{1}, the state variable feedback gain coefficient k of gridconnected current in the POLE PLACEMENT USING module is multiplied by the output of gridconnected side current detection module after the referential modular converter
_{3}, the state variable feedback gain coefficient k of capacitance voltage in the POLE PLACEMENT USING module is multiplied by the output of filter capacitor voltage detection module after the referential modular converter
_{2}, will after above three output additions, form the state feedback signal;
S7: calculate the output signal of variable gain module and the difference of state feedback signal and produce for regulating the also modulation signal of current on line side, modulation signal is input in the SPWM unit and compares with the triangular carrier signal SPWM pulsemodulated signal produced for the control inverter switch.
Described POLE PLACEMENT USING module and variable gain factor module are to adopt the feedback control module that realizes POLE PLACEMENT USING based on the system mode feedback; Described reference current synthesis module is by being synthesized based on instantaneous active power P and reactive power Q under α β stationary reference frame.
The foregoing is only the preferred embodiments of the present invention, be not limited to the present invention, obviously, those skilled in the art can carry out various changes and modification and not break away from the spirit and scope of the present invention the present invention.Like this, if within of the present invention these are revised and modification belongs to the scope of the claims in the present invention and equivalent technologies thereof, the present invention also is intended to comprise these changes and modification interior.
Claims (10)
1. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING, is characterized in that: comprise direct current input source, DC voltage detection module, inverter, inversion side current detection module, LCL filter, filter capacitor voltage detection module, gridconnected side current detection module, gridconnected point voltage detection module, the outer ring controller of power, gridconnected reference current synthesis module, current loop controller, variable gain factor module, POLE PLACEMENT USING module and SPWM unit;
Described direct current input source, for connecting outside direct current input source;
Described DC voltage detection module, for gathering DC side voltage of converter;
Described inverter, for realizing the conversion of direct current to alternating current;
Described inversion side current detection module, for gathering inversion side threephase alternating current;
Described LCL filter, for the highfrequency harmonic component of filtering inversion side output current;
Described filter capacitor voltage detection module, for gathering the threephase alternating voltage of LCL filter filter capacitor;
Described gridconnected side current detection module, for gathering gridconnected side threephase alternating current;
Described gridconnected point voltage detection module, for gathering and the site threephase alternating voltage;
The outer ring controller of described power, for stablizing DC side voltage of converter;
Described gridconnected reference current synthesis module, for calculating the gridconnected current setpoint;
Described current loop controller, for regulating gridconnected side current tracking gridconnected current setpoint;
Described variable gain factor module and POLE PLACEMENT USING module, for suppressing the impact of electric network impedance on the stability of a system;
Described SPWM unit, for providing the SPWM modulation signal, the conducting of control inverter switching device or shutoff;
Described direct current input source is connected with the input of inverter, and the output of described inverter is connected with the input of LCL filter, and the output of described LCL filter is connected with electrical network;
The inversion side of described LCL filter and gridconnected side are respectively arranged with inversion side current detection module and gridconnected side current detection module, the filter capacitor place of LCL filter is provided with the filter capacitor voltage detection module, and the output of described inversion side current detection module and filter capacitor voltage detection module is connected with the input of POLE PLACEMENT USING module; The output of described gridconnected side current detection module is connected with the input of POLE PLACEMENT USING module and current loop controller respectively;
The input of described POLE PLACEMENT USING module is connected with the output of inversion side current detection module, filter capacitor voltage detection module and gridconnected side current detection module, input signal forms the state feedback signal after being multiplied by respectively the state variable feedback gain coefficient k1, k3, k2 of inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, will after above three state feedback signal plus, with the output of variable gain factor module, do poor the connection;
Described and site is provided with voltage detection module, described gridconnected point voltage detection module output with the input of reference current synthesis module, be connected; The output of described reference current synthesis module is connected with the input of current loop controller, and the output of described current loop controller is connected with the input of variable gain factor module; The output of described variable gain factor module is done poor the connection with the output of described POLE PLACEMENT USING module, then with the input of SPWM unit, is connected;
Described inverter directflow side is provided with the DC side voltage of converter detection module, after the output of described DC side voltage of converter detection module and reference voltage signal are made difference, with the input of the outer ring controller of power, be connected, after the output signal of the outer ring controller of described power and the output multiplication of DC side voltage of converter detection module, output is connected with the input of reference current synthesis module.
2. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING according to claim 1, is characterized in that: also comprise the referential modular converter;
Described referential modular converter, for realizing the conversion between three phase static referential and twophase stationary reference frame;
The output of described inversion side current detection module, gridconnected side current detection module and filter capacitor voltage detection module is connected with the input of referential modular converter; The output of output after the referential modular converter of described inversion side current detection module and filter capacitor voltage detection module is connected with the input of POLE PLACEMENT USING module; The output of the output of described gridconnected side current detection module after the referential modular converter is connected with the input of POLE PLACEMENT USING module and current loop controller respectively;
The output of described gridconnected point voltage detection module is connected with the input of referential modular converter; The output of the output of described gridconnected point voltage detection module after the referential modular converter is connected with the input of reference current synthesis module; The output of described reference current synthesis module is connected with the input of current loop controller, and the output of described current loop controller is connected with the input of variable gain factor module; The output of described variable gain factor module is done poor the connection with the output of described POLE PLACEMENT USING module, then with the input of referential modular converter, is connected; The output of described referential modular converter is connected with the input of SPWM unit.
3. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING according to claim 1, is characterized in that: the PI controller of the outer ring controller employing of described power lowpass filter, the transfer function G of the outer ring controller of described PI power
_{cv}(s) expression formula is:
In formula, τ
_{0}mean proportionality constant, τ
_{2}mean integration time constant, τ
_{1}mean derivative time constant, s means that the transfer function expression formula provides with Laplce's form.
4. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING according to claim 1 is characterized in that: described gridconnected reference current synthesis module, calculate the gridconnected current setpoint by following formula:
Wherein,
be illustrated in the gridconnected current setpoint under the α stationary reference frame,
be illustrated in the gridconnected current setpoint under the β stationary reference frame, u
_{α}be illustrated in the gridconnected point voltage fundametal compoment under the α stationary reference frame, u
_{β}be illustrated in the electrical network point voltage fundametal compoment under the β stationary reference frame, Q
_{ref}mean the instantaneous reactive power setpoint, P
_{ref}mean the instantaneous active power setpoint.
5. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING according to claim 1, it is characterized in that: described current loop controller adopts accurate PR+HC current controller; The transfer function G of described accurate PR+HC current controller
_{c}(s) expression formula is:
In formula, k
_{p}mean proportional gain, h means firstharmonic and each harmonic component, k
_{rh}mean the improper integral coefficient, ω
_{c}mean the controller bandwidth factor, ω
_{1}mean resonance angular frequency, ω
_{1}the line voltage fundamental frequency of being extracted by gridconnected common point, s means that the transfer function expression formula provides with Laplce's form.
6. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING according to claim 1 is characterized in that: described variable gain module, calculate variable gain factor k in described variable gain factor module by following formula
_{a}:
Wherein, L
_{2}mean the gridconnected side inductance parameters of LCL filter value, L
_{g}mean equivalent inductance parameters value in electric network impedance.
7. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING according to claim 1, is characterized in that: the unsure state feedback signal of described POLE PLACEMENT USING module generation for suppressing the LCL filter resonance and being caused by electric network impedance; State variable feedback gain coefficient in described POLE PLACEMENT USING module obtains by following steps:
At first, calculate by following formula the active damping coefficient k that suppresses the LCL filter resonance
_{c}:
Wherein, ζ means system damping ratio, L
_{1}, L
_{2}, C
_{f}mean respectively LCL filter inverter side inductance, gridconnected side inductance and filter capacitor;
Then, calculate state feedback coefficient in the POLE PLACEMENT USING module by following formula:
In formula, k
_{1}, k
_{3}, k
_{2}the state variable feedback gain coefficient that means respectively inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, k
_{pwm}mean that modulating wave is to inverter bridge outputtransfer function, L
_{g}, R
_{g}mean respectively equivalent inductance and equivalent resistance in electric network impedance;
The state variable feedback gain coefficient k of inverter output current in the POLE PLACEMENT USING module is multiplied by the output of inversion side current detection module after the referential modular converter
_{1}, the state variable feedback gain coefficient k of gridconnected current in the POLE PLACEMENT USING module is multiplied by the output of gridconnected side current detection module after the referential modular converter
_{3}, the state variable feedback gain coefficient k of capacitance voltage in the POLE PLACEMENT USING module is multiplied by the output of filter capacitor voltage detection module after the referential modular converter
_{2}, will form the state feedback signal after above three output signal additions.
8. the threephase LCL type combining inverter control system based on POLE PLACEMENT USING according to claim 1, it is characterized in that: described SPWM unit produces the modulation signal for adjusting current on line side by the output signal of calculating variable gain module and the difference of state feedback signal, and modulation signal is input in the SPWM unit and compares the SPWM pulsemodulated signal of generation for the control inverter switch with the triangular carrier signal;
Described POLE PLACEMENT USING module and variable gain factor module are to adopt the feedback control module that realizes POLE PLACEMENT USING based on the system mode feedback; Described reference current synthesis module is by being synthesized based on instantaneous active power P and reactive power Q under α β stationary reference frame.
9. the control method of carrying out according to the described threephase LCL type combining inverter control system based on POLE PLACEMENT USING of claim 18 is characterized in that: comprise the following steps:
S1: form directcurrent reference current by the outer ring controller of power, stablize DC side voltage of converter; The outer ring controller of described power adopts the PI controller of lowpass filter, the transfer function G of the outer ring controller of described PI power
_{cv}(s) expression formula is:
In formula, τ
_{0}mean proportionality constant, τ
_{2}mean integration time constant, τ
_{1}mean derivative time constant, s means that the transfer function expression formula provides with Laplce's form;
S2: by following formula, calculate the gridconnected current setpoint:
Wherein,
be illustrated in the gridconnected current setpoint under the α stationary reference frame,
be illustrated in the gridconnected current setpoint under the β stationary reference frame, u
_{α}be illustrated in the gridconnected point voltage positive sequence fundametal compoment under the α stationary reference frame, u
_{β}be illustrated in the line voltage positive sequence fundametal compoment under the β stationary reference frame, Q
_{ref}mean the instantaneous reactive power setpoint, P means the instantaneous active power setpoint;
The output signal of described gridconnected side current detection module is after the referential modular converter, poor with the gridconnected current setpoint, the input of its formed error signal input current ring controller;
S3: by the current loop controller effect, produce for regulating the also conditioning signal of current on line side, described current loop controller adopts accurate PR+HC current controller; The transfer function G of described accurate PR+HC current controller
_{c}(s) expression formula is:
In formula, k
_{p}mean proportional gain, h means firstharmonic and each harmonic component, k
_{rh}mean the improper integral coefficient, ω
_{c}mean the controller bandwidth factor, ω
_{1}mean resonance angular frequency, ω
_{1}the line voltage fundamental frequency of being extracted by gridconnected common point, s means that the transfer function expression formula provides with Laplce's form;
S4: the output regulation signal of current loop controller, suppress the impact on the stability of a system of LCL filter resonance and electric network impedance by variable gain module, eliminate the impact of electric network impedance on conditioning signal; Calculate variable gain factor k in described variable gain factor module by following formula
_{a}:
Wherein, L
_{2}mean the gridconnected side inductance parameters of LCL filter value, L
_{g}mean equivalent inductance parameters value in electric network impedance;
S5: gather inversion side electric current, filter capacitor voltage and and current on line side be input to the POLE PLACEMENT USING module;
S6: by the POLE PLACEMENT USING module, produce the unsure state feedback signal for suppressing the LCL filter resonance and being caused by electric network impedance;
The state feedback signal of described POLE PLACEMENT USING module output obtains by following steps:
At first, calculate by following formula the active damping coefficient k that suppresses the LCL filter resonance
_{c}:
Wherein, ζ means system damping ratio, L
_{1}, L
_{2}, C
_{f}mean respectively LCL filter inverter side inductance, gridconnected side inductance and filter capacitor;
Then, calculate feedback factor in the POLE PLACEMENT USING module by following formula:
In formula, k
_{1}, k
_{3}, k
_{2}the state variable feedback gain coefficient that means respectively inverter output current, gridconnected current and capacitance voltage in the POLE PLACEMENT USING module, k
_{pwm}mean that modulating wave is to inverter bridge outputtransfer function, L
_{g}, R
_{g}mean respectively equivalent inductance and equivalent resistance in electric network impedance;
The state variable feedback gain coefficient k of inverter output current in the POLE PLACEMENT USING module is multiplied by the output of inversion side current detection module after the referential modular converter
_{1}, the state variable feedback gain coefficient k of gridconnected current in the POLE PLACEMENT USING module is multiplied by the output of gridconnected side current detection module after the referential modular converter
_{3}, the state variable feedback gain coefficient k of capacitance voltage in the POLE PLACEMENT USING module is multiplied by the output of filter capacitor voltage detection module after the referential modular converter
_{2}, will after above three output additions, form the state feedback signal;
S7: calculate the output signal of variable gain module and the difference of state feedback signal and produce for regulating the also modulation signal of current on line side, modulation signal is input in the SPWM unit and compares with the triangular carrier signal SPWM pulsemodulated signal produced for the control inverter switch.
10. the threephase LCL type control method of gridconnected inverter based on POLE PLACEMENT USING according to claim 9 is characterized in that: described POLE PLACEMENT USING module and variable gain factor module are to adopt the statebased feedback to realize the feedback control module of POLE PLACEMENT USING; Described reference current synthesis module is by being synthesized based on instantaneous active power P and reactive power Q under α β stationary reference frame.
Priority Applications (1)
Application Number  Priority Date  Filing Date  Title

CN201310449942.3A CN103475029B (en)  20130927  20130927  Threephase LCL type gridconnected inverter control system and method based on pole assignment
Applications Claiming Priority (1)
Application Number  Priority Date  Filing Date  Title

CN201310449942.3A CN103475029B (en)  20130927  20130927  Threephase LCL type gridconnected inverter control system and method based on pole assignment
Publications (2)
Publication Number  Publication Date

CN103475029A true CN103475029A (en)  20131225
CN103475029B CN103475029B (en)  20150408
Family
ID=49799773
Family Applications (1)
Application Number  Title  Priority Date  Filing Date

CN201310449942.3A Active CN103475029B (en)  20130927  20130927  Threephase LCL type gridconnected inverter control system and method based on pole assignment
Country Status (1)
Country  Link

CN (1)  CN103475029B (en)
Cited By (16)
Publication number  Priority date  Publication date  Assignee  Title

CN104022532A (en) *  20140623  20140903  珠海格力电器股份有限公司  Girdconnected inverter control method and system for photovoltaic power generation system
CN104037802A (en) *  20140606  20140910  浙江大学  Photovoltaic gridconnected inverter control method based on linear phase repetition controller (LPRC)nonlinear proportional integral (NLPI) combined controller
CN105119318A (en) *  20150910  20151202  大连理工大学  Gridconnected converter antiinterference capabilitybased similar synchronous machine additional damping control method
CN105356507A (en) *  20151123  20160224  合肥工业大学  Power grid impedance selfadaption based LC type gridconnected inverter dualmode control method
CN105490301A (en) *  20160118  20160413  上海电力学院  Gridconnected inverter system parameter adjusting method based on sensitivity analysis
CN105762822A (en) *  20160517  20160713  国网安徽省电力公司芜湖供电公司  Gridconnected structure of compressed air energy storage system
CN106655270A (en) *  20161229  20170510  华中科技大学  Control method for suppressing rectification start impact current of threephase LCL type grid connection converter
CN107134936A (en) *  20170522  20170905  天津威瀚电气股份有限公司  A kind of inverter active damping control method based on overallfinished housing
CN107681686A (en) *  20170919  20180209  厦门科华恒盛股份有限公司  A kind of combining inverter and its harmonic suppressing method and photovoltaic parallel in system
CN108023352A (en) *  20171127  20180511  国网宁夏电力有限公司经济技术研究院  Suppress the power grid highfrequency impedance remodeling device and method of distributed power generation resonance
CN108227499A (en) *  20180116  20180629  北京航空航天大学  A kind of magnetic suspension rotor method for inhibiting harmonic current of harmonic oscillator parallel connection fractional order repetitive controller
CN108390585A (en) *  20180309  20180810  林春旭  The low harmony wave control system of singlephase H6 girdconnected inverters
CN108964084A (en) *  20180705  20181207  湖南大学  The improved belt of multimachine parallel connection system hinders filter highfrequency oscillation suppression method
CN109193792A (en) *  20181116  20190111  燕山大学  The SOCVF feedforward of girdconnected inverter and phase compensating factor method for handover control under weak grid
CN109217361A (en) *  20180820  20190115  江苏大学  A kind of novel photovoltaic gridconnected inverter composite control method based on OSAP and improvement bimode control
CN111277163A (en) *  20200302  20200612  上海电气集团股份有限公司  Fault identification control method for realizing active damping based on FPGA and improved voltage reconstruction
Citations (7)
Publication number  Priority date  Publication date  Assignee  Title

CN102118028A (en) *  20110127  20110706  华中科技大学  Method for suppressing and controlling current harmonics of threephase LCL (Lower Control Limit) type gridconnected inverter
EP2362515A1 (en) *  20100219  20110831  ABB Research Ltd  Control method for singlephase gridconnected LCL inverter
CN102222933A (en) *  20110610  20111019  南京航空航天大学  Network access current control method for singlephase less container load (LCL) filtering gridconnected inverter
CN102340257A (en) *  20110902  20120201  南京航空航天大学  Doublecurrent loop control method of LCL (Inductor Capacitor Inductor) filtering gridconnected inverter
CN102761138A (en) *  20120731  20121031  慈溪市宇时通信电力设备有限公司  LCL type gridconnected inverter without resonance damping and integrated design method thereof
CN103248259A (en) *  20130416  20130814  湖南大学  Singlecurrent feedback control method of threephase LCL (lower control limit) filtering type PWM (pulsewidth modulation) rectifier
CN103326386A (en) *  20130705  20130925  合肥工业大学  Capacitorvoltagebased gridconnected inverter active damping method

2013
 20130927 CN CN201310449942.3A patent/CN103475029B/en active Active
Patent Citations (7)
Publication number  Priority date  Publication date  Assignee  Title

EP2362515A1 (en) *  20100219  20110831  ABB Research Ltd  Control method for singlephase gridconnected LCL inverter
CN102118028A (en) *  20110127  20110706  华中科技大学  Method for suppressing and controlling current harmonics of threephase LCL (Lower Control Limit) type gridconnected inverter
CN102222933A (en) *  20110610  20111019  南京航空航天大学  Network access current control method for singlephase less container load (LCL) filtering gridconnected inverter
CN102340257A (en) *  20110902  20120201  南京航空航天大学  Doublecurrent loop control method of LCL (Inductor Capacitor Inductor) filtering gridconnected inverter
CN102761138A (en) *  20120731  20121031  慈溪市宇时通信电力设备有限公司  LCL type gridconnected inverter without resonance damping and integrated design method thereof
CN103248259A (en) *  20130416  20130814  湖南大学  Singlecurrent feedback control method of threephase LCL (lower control limit) filtering type PWM (pulsewidth modulation) rectifier
CN103326386A (en) *  20130705  20130925  合肥工业大学  Capacitorvoltagebased gridconnected inverter active damping method
Cited By (24)
Publication number  Priority date  Publication date  Assignee  Title

CN104037802A (en) *  20140606  20140910  浙江大学  Photovoltaic gridconnected inverter control method based on linear phase repetition controller (LPRC)nonlinear proportional integral (NLPI) combined controller
CN104037802B (en) *  20140606  20160302  浙江大学  A kind of photovoltaic combining inverter control method based on LPRCNLPI composite controller
CN104022532A (en) *  20140623  20140903  珠海格力电器股份有限公司  Girdconnected inverter control method and system for photovoltaic power generation system
CN105119318A (en) *  20150910  20151202  大连理工大学  Gridconnected converter antiinterference capabilitybased similar synchronous machine additional damping control method
CN105119318B (en) *  20150910  20170721  大连理工大学  Homochronousness machine additional longitudinal forces method based on gridconnected converter interference rejection ability
CN105356507B (en) *  20151123  20170829  合肥工业大学  Based on the adaptive LC type combining inverter doublemode control methods of electric network impedance
CN105356507A (en) *  20151123  20160224  合肥工业大学  Power grid impedance selfadaption based LC type gridconnected inverter dualmode control method
CN105490301A (en) *  20160118  20160413  上海电力学院  Gridconnected inverter system parameter adjusting method based on sensitivity analysis
CN105762822A (en) *  20160517  20160713  国网安徽省电力公司芜湖供电公司  Gridconnected structure of compressed air energy storage system
CN106655270B (en) *  20161229  20190618  华中科技大学  Inhibit the control method of threephase LCL type gridconnection converter rectification inrush current
CN106655270A (en) *  20161229  20170510  华中科技大学  Control method for suppressing rectification start impact current of threephase LCL type grid connection converter
CN107134936A (en) *  20170522  20170905  天津威瀚电气股份有限公司  A kind of inverter active damping control method based on overallfinished housing
CN107681686A (en) *  20170919  20180209  厦门科华恒盛股份有限公司  A kind of combining inverter and its harmonic suppressing method and photovoltaic parallel in system
CN107681686B (en) *  20170919  20200211  科华恒盛股份有限公司  Gridconnected inverter, harmonic suppression method thereof and photovoltaic gridconnected system
CN108023352B (en) *  20171127  20210122  国网宁夏电力有限公司经济技术研究院  Power grid highfrequency impedance remodeling device and method for inhibiting distributed generation resonance
CN108023352A (en) *  20171127  20180511  国网宁夏电力有限公司经济技术研究院  Suppress the power grid highfrequency impedance remodeling device and method of distributed power generation resonance
CN108227499A (en) *  20180116  20180629  北京航空航天大学  A kind of magnetic suspension rotor method for inhibiting harmonic current of harmonic oscillator parallel connection fractional order repetitive controller
CN108390585A (en) *  20180309  20180810  林春旭  The low harmony wave control system of singlephase H6 girdconnected inverters
CN108964084B (en) *  20180705  20210402  湖南大学  Improved bandstop filter highfrequency oscillation suppression method for multimachine parallel system
CN108964084A (en) *  20180705  20181207  湖南大学  The improved belt of multimachine parallel connection system hinders filter highfrequency oscillation suppression method
CN109217361A (en) *  20180820  20190115  江苏大学  A kind of novel photovoltaic gridconnected inverter composite control method based on OSAP and improvement bimode control
CN109193792A (en) *  20181116  20190111  燕山大学  The SOCVF feedforward of girdconnected inverter and phase compensating factor method for handover control under weak grid
CN111277163A (en) *  20200302  20200612  上海电气集团股份有限公司  Fault identification control method for realizing active damping based on FPGA and improved voltage reconstruction
CN111277163B (en) *  20200302  20210504  上海电气集团股份有限公司  Fault identification control method for realizing active damping based on FPGA and improved voltage reconstruction
Also Published As
Publication number  Publication date

CN103475029B (en)  20150408
Similar Documents
Publication  Publication Date  Title

CN103475029B (en)  Threephase LCL type gridconnected inverter control system and method based on pole assignment
CN101534065B (en)  Asymmetric direct power control method of gridconnected threephase voltage source converter
CN103227581B (en)  Inverter parallel harmonic wave ring current restraining method for controlling harmonic wave droop
CN103151785B (en)  Multiconverter parallel circulating current restraining method with quick and reactive support
CN103872703B (en)  A kind of control system for solving low voltage crossing and strategy process thereof
CN105244919B (en)  A kind of robust compensation of delay gridconnected control method of LCL type inverter
CN104218590A (en)  Unbalance voltage compensation and control method based on virtual synchronous machine
CN103326386B (en)  Capacitorvoltagebased gridconnected inverter active damping method
CN104158220B (en)  The virtual reactance control method of photovoltaic combining inverter
CN103475033B (en)  Current control method and system for threephase LCL type gridconnected inverter without phase locking link
CN103326399B (en)  Gridconnected inverter control method under unbalanced and harmonic wave power grids
CN101944840A (en)  Control method for eliminating DC harmonic voltage for gridside converter of doublefed wind power generator
CN102142694B (en)  Rotational coordinate transformation based current decoupling control method for threephase gridconnected inverter
CN103560690A (en)  Harmonic wave damping control method for onephase LCL type gridconnected inverter
CN104377727A (en)  Unbalanced control method for gridconnected inverter multitarget collaborative optimization
CN104078976B (en)  Harmonic suppressing method, device and the photovoltaic system of a kind of photovoltaic system gridconnected current
CN104578167A (en)  Power feedforward control method for single stage type threephase photovoltaic gridconnected inverter
CN102723740A (en)  Stable MPPT (Maximum Power Point Tracking) control system and method of singlestage photovoltaic inverter
CN102629768A (en)  Photovoltaic gridconnected inverter current control method based on positive and negative sequence component separation
CN103888007A (en)  Inverter parallelconnection loop current restraining system based on PR control and dualcarrier modulation
CN108923463B (en)  Frequency coupling modeling method of singlephase LCL type gridconnected inverter considering phaselocked loop
CN107394779B (en)  Dynamic performance optimization control method for microgrid active power filter
CN105763094A (en)  Inverter control method based on voltage feedforward and recombination current control
CN105553309A (en)  Ttype threelevel inverter and midpoint balance control method thereof
CN105514972A (en)  PSCAD modeling and simulation method for gridconnected inverter during unsymmetrical failure of power grid
Legal Events
Date  Code  Title  Description

C06  Publication
PB01  Publication
C10  Entry into substantive examination
SE01  Entry into force of request for substantive examination
C14  Grant of patent or utility model
GR01  Patent grant
